Description
BAUTRAX SPC50 is a spider crane with 5 ton lifting capacity, a maximum operating radius of 15 m and maximum ground lift of 17 m. The stated reach supports installation and lifting tasks requiring a larger working envelope than compact lower-capacity cranes.
The crane uses a YuChai 490 engine with electric starting and hydraulic motor travel drive. Its 4 m × 5-section boom extends from 4.5 to 17 m in 54 seconds, while continuous rotation from 0 to 360° is completed in 38 seconds.
Lifting capacity: 5 ton
Maximum operating radius: 15 m
Maximum ground lift: 17 m
Hook lifting speed: 12 m/min with 4 ropes
Walking speed: 0–2.5 km/h
Gradeability: 25° (36%)
Weight: 6100 kg
Application: Suitable for lifting and installation work requiring 5 ton capacity, extended boom reach and a stabilised spider-crane footprint. The maximum deployed dimensions are 5800 × 4900 × 5600 mm.
The crane uses diesel fuel with an 8 L stated volume.
Technical specifications
| Parameter | Value |
|---|---|
| Weight | 6100 kg. |
| Gradeability | 25° (36%) |
| Engine Brand | YuChai |
| Engine Type | 490 |
| Starting Mode | Electric start |
| Lift Capacity | 5 ton |
| Maximum Operating Radius | 15 m |
| Maximum Ground Lift | 17 m |
| Hook Lifting Speed | 12 m/min (4 ropes) |
| Steel Rope Specification | Φ12 mm × 80 m |
| Boom Form | 4 m × 5-section lifting arm |
| Boom Length / Time | 4.5–17 m / 54 sec |
| Rotation Angle / Speed | 0–360° continuous / 38 sec |
| Outrigger Movement Form | Manual screw out + oil pressure automatic support (two legs) |
| Maximum Extension Amplitude | 5800 × 4900 × 5600 mm |
| Walking Mode | Hydraulic motor drive |
| Fuel / Volume | Diesel oil / 8 L |
| Operation Type | Manual operation and walking |
| Walking Speed | 0–2.5 km/h |
| Parameter | Value |
|---|---|
| Weight | 6100 kg. |
| Gradeability | 25° (36%) |
| Engine Brand | YuChai |
| Engine Type | 490 |
| Starting Mode | Electric start |
| Lift Capacity | 5 ton |
| Maximum Operating Radius | 15 m |
| Maximum Ground Lift | 17 m |
| Hook Lifting Speed | 12 m/min (4 ropes) |
| Steel Rope Specification | Φ12 mm × 80 m |
| Parameter | Value |
|---|---|
| Boom Form | 4 m × 5-section lifting arm |
| Boom Length / Time | 4.5–17 m / 54 sec |
| Rotation Angle / Speed | 0–360° continuous / 38 sec |
| Outrigger Movement Form | Manual screw out + oil pressure automatic support (two legs) |
| Maximum Extension Amplitude | 5800 × 4900 × 5600 mm |
| Walking Mode | Hydraulic motor drive |
| Fuel / Volume | Diesel oil / 8 L |
| Operation Type | Manual operation and walking |
| Walking Speed | 0–2.5 km/h |
